Tuesday's Tips: A Smokin' Workshop!

Recently I hosted a smokin’ workshop at my studio in Boston’s historic South End.   Actually it wasn’t smoke, it was fog from a Rosco fog machine!

This workshop was a 2 day advanced Location Lighting Workshop and everyone who attended had previously taken one of my workshops.  We decided to create a complex lighting job!

It was a slightly rainy day in the courtyard behind the studio, so all the strobes and electrical connections had to be covered in plastic.  The courtyard is 22’ x 40’  minus the space for the garden, we had about 15’ x 30’ to work in.  The key to photographing smoke is to back-light it.  I will introduce you 2 smokin' lighting set ups from the workshop in this blog.

Set Up 1

Main light was Dyna lite Baja 600 with Chimera strip light with barn doors to control the direction of the light.  We set up another Dynalite Baja directly behind the model with a 20 degree grid anda Rosco blue gel.  We placed 4 Nissin speedlights with different color Rosco gels in ziplock bags on the ground and in the tree.  The lantern was lit with amini optical slave with Rosco yellow gel and a piece of Rosco Toughspun to cut the exposure . A cross screen filter was used to create the star effect. Rosco fog machine was at stage left, just outside the frame.

Nikon D810 Lens (mm): 46 ISO: 200 Aperture: 7.1 Shutter: 1/250

Nikon D810 Lens (mm): 46
ISO: 200
Aperture: 7.1
Shutter: 1/250

In this photograph we changed some of the filters and removed the cross screen filter.

Nikon D810 with a Nikon 24-120 f4. lens. ISO: 200 Aperture: 7.1 Shutter: 1/250

Nikon D810 with a Nikon 24-120 f4. lens.
ISO: 200
Aperture: 7.1
Shutter: 1/250





Here is what the courtyard looked like without lighting.

Gear used:

1 Rosco Mini V Fog Machine
5 Rosco gels from my Rosco Location Lighting Kit
2 Dynalite Baja strobes, 1, 400ws and 1 600 ws
4 Nissin Di700A flashes ( in plastic bags to protect from the rain)
1 Chimera strip light with barn doors
1 mini flash with an optical slave
5 Pocket Wizard Plus III
2 Pocket Wizard Plus IV
2 PhotoFlex light stands
1 cross screen filter



Set Up 2

This is 2 Dynalite Baja and 1 Nissin speedlight set up.  1 Dynalite Baja with a Chimera strip light as main light and the other with a grid and Rosco blue gel as back light.  There is a Nissin speeslight with Rosco red gel in background as well.

Nikon D810 Lens (mm): 100 ISO: 100 Aperture: 4 Shutter: 1/100

Nikon D810 Lens (mm): 100
ISO: 100
Aperture: 4
Shutter: 1/100



Behind the scene.

Gear used:

3 Rosco gels from my Rosco Location Lighting Kit
2 Dynalite Baja strobes, 1, 400ws and 1 600 ws
1 Nissin Di700A flash
1 Chimera strip light with barn doors
1Pocket Plus III
2 Pocket Wizard Plus IV


Here is our silly group photograph from the smokin' workshop!  Thank you for everyone attending.  Last but not the least, thank you for good friends at Rosco for lending us the fog machine!

Nikon D810 Lens (mm): 24 ISO: 500 Aperture: 10 Shutter: 1/250

Nikon D810 Lens (mm): 24
ISO: 500
Aperture: 10
Shutter: 1/250

I will be at Unique Photo Expo 2016 on June 24 through 26! Hope to see you there!

Happy Lighting! and Please Don't Feed the Models!
